What is Luban

Luban is a configuration solution for game projects: it describes config structure with a unified type system, reads data from Excel / JSON / XML and more, validates it, then generates multi-language code and multiple data formats.

It is not merely “convert Excel to JSON.” It puts designer spreadsheets, program loading, client/server split exports, and complex gameplay data (skills, behavior trees, dungeons, and so on) into one pipeline.

Who it is for​

RoleWhat you use
ProgrammerDefine schema, write generation commands, load with Tables at runtime
DesignerFill data in Excel (or editor-exported JSON) following the conventions

Core capabilities (overview)​

  • Type system: primitive types, enums, beans, inheritance/polymorphism, containers, nullable
  • Multiple data sources: Excel family, JSON, XML, YAML, Lua, and more
  • Multi-target export: groups / targets control what client, server, and editor each receive
  • Validation: references, ranges, asset paths, and more—catch errors at generation time when possible
  • Multiple languages and formats: C# / Java / Go / Lua / TS…; bin / json / protobuf…
  • Extensible: Loader, Validator, CodeTarget, DataTarget, and Pipeline can all be plugged in

Full feature list: Luban feature list.

Good fit and poor fit​

Good fit

  • Client and server need to share one set of config definitions
  • Table structure will grow from “flat row lists” into nesting and polymorphism
  • You want strongly typed loading code generated, not hand-written parsers

Poor fit

  • Only a few trivial key-value sheets, and you never need types / validation / multi-target export
  • You refuse to have programmers maintain schema (Luban treats schema as a contract: data that does not conform should error, not rewrite the definition)

Official resources​

  • Example projects: luban_examples (includes MiniTemplate and multi-engine samples)
  • Source: luban
  • Unity Runtime: luban_unity
  • QQ group: 692890842 · Discord: see the repository README
